FEATURES:
Single stage construction
Forged brass body for maximum strength
High strength alloy housing cap
Neoprene steel diaphragms
Oxygen regulator with safety relief valve is set for safe operation
Sintered metal inlet filter to trap impurities
No soldered joints, for easy maintenance
Side entry
Model | Gas | Max. Inlet Pressure(PSI) | Delivery Pressure(PSI) | Max. Working Pressure(PSI) |
SR255-OX | Oxygen | 3000 | 200 | 150 |
SR255-AC | Acetylene | 300 | 15 | 10 |
SR255-AR | Argon | 3000 | 200 | 150 |
SR255-NI | Nitrogen | 3000 | 200 | 150 |
