| Tip | Cutting Thickness (mm) | Cutting Oxygen (psig) | Fuel (psig) | Orifice (mm) |
| 375-00 | 1-3 | 1.0-1.5 | 0.3 | 0.8 |
| 375-0 | 3-6 | 1.0-2.0 | 0.3 | 1.0 |
| 375-1 | 6-10 | 1.5-2.5 | 0.3 | 1.2 |
| 375-2 | 10-20 | 2.0-3.0 | 0.4 | 1.4 |
| 375-3 | 20-40 | 2.5-3.5 | 0.4 | 1.6 |
| 375-4 | 40-60 | 3.0-4.0 | 0.4 | 1.8 |
| 375-5 | 60-80 | 3.5-4.5 | 0.5 | 2.0 |
| 375-6 | 80-125 | 4.5-5.5 | 0.5 | 2.4 |
| 375-7 | 125-200 | 5.5-6.5 | 0.5 | 2.8 |
| 375-8 | 200-250 | 6.0-7.0 | 0.8 | 3.2 |
| 375-9 | 250-300 | 6.0-7.0 | 0.8 | 3.6 |
| 375-10 | 300-350 | 6.0-7.0 | 0.8 | 4.2 |
